    Polcd ILI8961 2.7 Tft Lcd 960X240 TFT LCD Display RGB 8 Bit 6 0'CLOCK

    Ask Lasest Price
    Brand Name : Polcd
    Model Number : P027-40-V2
    Certification : RoHS, ISO9001
    Price : Please contact us for latest price
    Payment Terms : T/T, L/C, Credit card, PayPal
    Supply Ability : 500,000 piece per week
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Polcd ILI8961 2.7 Tft Lcd 960X240 TFT LCD Display RGB 8 Bit 6 0'CLOCK

    Description:

    2.7 inch TFT LCDs (Thin-Film Transistor Liquid Crystal Displays) are commonly used in various electronic devices that require a small-size display with good image quality.

    It offer a reliable and versatile display solution for various applications, providing high-quality display performance, low power consumption, and customization options to meet specific application requirements.


    Parameter:

    ModelP027-40-V2
    Screen Size2.7 inch
    Number of Pixel960RGB(H)x240(V)
    Display area40.50(H)x54.00(V)mm
    Pixel pitch0.05625(H)x0.16875(V)mm
    Pins40 pins
    Outline Dimension46.20x63.10x2.38mm
    Pixel arrangementRGB Vertical Stripe
    Display modeNormally White
    Viewing Direction(eye)6 0'CLOCK
    Display Color262K
    Luminance(cd/m2)230 nit
    Contrast Ratio600:1
    InterfaceRGB 8bit
    Back-lightLED Side-light type
    Drive ICILI8961
    Operation Temperature-30~80℃
    Storage Temperature-30~80℃
